Tracing Settings for xUML Services in Kubernetes

In Kubernetes setups, the trace files are stored to the PAS MinIO (S3), the trace meta data is stored to the PAS MariaDB. Kafka is used to synchronize the trace settings over multiple instances of an xUML service.

• The maximum storage space for tracing is 10 GB. If this limit is exceeded, no traces can be stored anymore, and errors are reported in the Analyzer.
  By this, it is ensured that sufficient free memory space is available for the correct operation of PAS at any time.

• By default, the trace files expire after 14 days. Files that are older than 14 days are automatically removed from MinIO (S3).

• The trace file retention time can be configured on your PAS instance. Please contact our support if you want to change the default configuration.

• The trace meta data is not automatically removed from the MariaDB.

For more information about xUML tracing and the usage of the xUML Trace Analyzer, refer to Using the xUML Trace Analyzer in the Analyzer Guide.
